MG 3







The MG3 is fully automatic weapon for sustained firing and firing in bursts. It is a"Recoil-operated weapon" in which the recoil forces are used to feed and load the  cartridges and to extract and eject the spent cartridge cases. A blank firing attachment, which is screwed onto the muzzle instead of the recoil booster, permits the use of blank cartridges for training and exercise purposes.




Calibre 7.62mm x 51 NATO
Feed device         Disintegrating and non-disintegrating belts
Type of fire Fully automatic
Operating principle Recoil operated
Rate of fire 1,150 ± 150 RPM
Sighting device Open sighting, using front and rear sights from 200 to 1,200 metres
Maximum range 4,000 metres
Max. effective range Bipod, 800 metres; tripod, 2,200 metres
Length of standard weapon 1,225 mm
Length of barrel with locking  piece 565 mm
Weight of weapon without  bipod & sling 10.5 kg
Rifling 4 grooves, rh, 1 turn in 305mm
